Micro Gain Solid Carbide Centre Drills

We bring forth to our clients a wide array of Micro Grain Solid Carbide Centre Drills. The drills offered by us, can be used for High Production applications. Further , these drills are also suitable for Countersinking and Drilling in various difficult materials, including angle available with 600 & 1200.

Technical Specifications :

Pilot Dia MM	Body Dia MM	OAL MM	Uncoated	TIN Coated	TIAIN
2.00	5.00	50	1720	1,801.00	1,885.00
2.50	6.00	50	2547	2,645.00	2,743.00
3.15	8.00	65	3077	3,235.00	3,393.00
4.00	10.00	65	3931	4,097.00	4,264.00
5.00	12.50	65	4593	4,792.00	4,992.00
6.30	16.00	75	7067	7,262.00	7,457.00
8.00	20.00	80	10025	10,341.00	10,655.00



Micro Grain Solid Carbide Jobber Drills

We hold expertise in offering a wide range of Micro Grain Solid Carbide Jobber Drills. Our drills are especially manufactured with 25° helix angle & 120 point angle, which allow high feed rate and good chip removal. These drills are extensively recommended for Drilling the Aluminium, Cast Iron, Plastics and other related easily machined materials.

Stub Series Micro Grain HP Stub Carbide Drills

We provide our clients with a wide range of Stub Series Micro Grain HP Stub Carbide Drills. These are available with a more robust design for improving the drill accuracy along with 30° helix & 140° point angle and also with self centering geometry. Besides, these drills are also ideal for Drilling the Alloyed Steel, Stainless Steel, Gray Iron and many others..

Micro Grain HP Solid Carbide Internal Coolant Drills

We are engaged in offering a wide range of high quality Micro Grain HP Solid Carbide Internal Coolant Drills. These drills are especially designed for Heavy Chip Removals. And High Feed Rates. Suitable for Alloy Steel and Machining Cat Iron Stainless Steel, these are further best suited for those applications, where the drilling depth is more is more (L/D=>5).
